PCI Express PCIe to 4 Port RS232 DB9 Serial Card MosChip MCS9904

PCI Express to Serial Port Card (4 x Serial Ports)

Features

• Fully compliant with PCI Express Base Specification, Revision 1.0a
• PCIe Multi Function Peripheral controller with x1 Lane Interface
• Support for D1, D2, D3hot and D3cold
• Support PCIe Power Management

Specifications

• 16C450/550/Extended 550 compatible UARTs
• Supports RS232, RS485 & RS422 modes (need a RS232 to RS485/RS422 Adaptor)
• Bi-directional speeds from 50 bps to 16Mbps/Port
• Full Serial Modem Control
• Supports Hardware, Software flow control
• 5, 6, 7, 8 and 9-bit Serial format Support
• Even, Odd, None, Space & Mark parity supported
• Custom BAUD Rates supported with external clock or by programming internal PLL
• On Chip 256 Byte depth FIFOs in Transmit, Receive path of each Serial Port
• Supports remote wakeup and power management features
• Serial Port transceiver shutdown support
• Support slow IrDA on all Serial Ports

OS Supported

• Windows 32bit 2000/XP/2003 Sever/Vista and 64bit XP/2003 Server/Vista
• Linux Kernel 2.6.11 & above
• Mac 10.4 & above
